We manufacture 5 models of foldable portable solar panels at our Fujian facility. Every panel uses monocrystalline silicon cells — the highest-efficiency commercially available cell chemistry — laminated into a compact foldable package that reduces transport volume by 50-75% compared to rigid glass panels. Our lineup spans two voltage tiers: the 18V compact series (BF-PV-F30W, BF-PV-F60W, BF-PV-F100W) for 12V-system devices, and the 36V high-power series (BF-PV-F200W, BF-PV-F400W) for 24V-system devices and larger power stations. The 30W, 60W, and 100W models include an integrated quick-charge junction box with USB-C PD 60W and USB QC 3.0 outputs — charge phones, tablets, and laptops directly from sunlight without any battery in between. We ship to campers, RV travelers, off-grid installers, and emergency preparedness distributors worldwide.
Our panels pair seamlessly with the BF-PPS portable power station series — no adapters, no voltage converters. The 18V panels connect directly to the BF-PPS-300W and BF-PPS-600W via DC5521 or XT60. The 36V panels connect to the BF-PPS-1500W and BF-PPS-3000W via XT60 or MC4. The BF-PV-F series is also compatible with third-party power stations and charge controllers using standard XT60 and MC4 connectors — no proprietary lock-in.
Portable Solar Panel Specifications
All models use monocrystalline silicon cells for maximum energy conversion per square centimeter. The 18V and 36V tiers are designed for different battery voltage systems — choose the tier that matches your power station or charge controller input range.
18V Compact Series (30W / 60W / 100W)
The compact series targets personal electronics, small power stations, and direct USB device charging. Every model includes a built-in quick-charge junction box with USB and PD outputs — no external charger or battery required for phone and laptop charging.
| Spec | BF-PV-F30W | BF-PV-F60W | BF-PV-F100W |
|---|---|---|---|
| Output Power | 30W | 60W | 100W |
| Output Voltage | 18V | 18V | 18V |
| Output Current | 1.67A | 3.33A | 5.55A |
| Cell Type | Monocrystalline Silicon | Monocrystalline Silicon | Monocrystalline Silicon |
| Unfolded Size | 670 × 325 × 15 mm | 950 × 485 × 20 mm | 1425 × 485 × 20 mm |
| Folded Size | 225 × 325 × 20 mm | 475 × 485 × 20 mm | 475 × 485 × 20 mm |
| Fold Count | 3-fold | 2-fold | 3-fold |
| Net Weight | 1.0 kg | 2.0 kg | 3.0 kg |
| Junction Box | DC5521 + USB QC 18W | XT60 + PD 60W + USB QC 18W | XT60 + PD 60W + USB QC 18W |
| Protocol Support | Apple 2.4A, Samsung 2A, DCP 1.5A, QC 2.0/3.0, Samsung AFC 9V | BC1.2, Apple, Samsung, QC 2.0/3.0 | BC1.2, Apple, Samsung, QC 2.0/3.0 |
| Compatible Power Station | BF-PPS-300W | BF-PPS-300W / BF-PPS-600W | BF-PPS-600W / BF-PPS-1500W |
36V High-Power Series (200W / 400W)
The high-power series targets large power stations, 24V battery systems, and grid-tie micro-inverters. These panels output raw DC via XT60 and MC4 connectors — a charge controller or compatible power station is required to regulate voltage for end devices.
| Spec | BF-PV-F200W | BF-PV-F400W |
|---|---|---|
| Output Power | 200W | 400W |
| Output Voltage | 36V | 36V |
| Output Current | 5.56A | 11.12A |
| Cell Type | Monocrystalline Silicon | Monocrystalline Silicon |
| Unfolded Size | 2070 × 600 × 10 mm | 2550 × 900 × 10 mm |
| Folded Size | 550 × 600 × 30 mm | 650 × 900 × 30 mm |
| Fold Count | 4-fold | 4-fold |
| Net Weight | 6.0 kg | 12.0 kg |
| Junction Box | XT60 / MC4 (quick-charge box optional) | XT60 / MC4 (quick-charge box optional) |
| Protocol Support (optional box) | BC1.2, Apple, Samsung, QC 2.0/3.0 | BC1.2, Apple, Samsung, QC 2.0/3.0 |
| Compatible Power Station | BF-PPS-1500W / BF-PPS-3000W | BF-PPS-3000W |
Quick-Charge Junction Box Specifications
The quick-charge junction box is an integrated charging hub built into the panel frame. It converts raw solar DC into regulated outputs for USB devices — no external charge controller needed for personal electronics.
30W Panel Junction Box (Standard on BF-PV-F30W):- DC output: 3A, unregulated, with 5A reverse-polarity diode
- USB-A QC 3.0: 18W max (5V/3A, 9V/2A, 12V/1.5A)
- Output connector: DC5521
- Protocol support: Apple 2.4A, Samsung 2A, DCP 1.5A, QC 2.0, QC 3.0, Samsung AFC 9V
- Included accessories: 0.75mm² DC5521 cable, MC4 adapter, carabiner
- XT60 DC output: 18V, 15A max, MOSFET reverse-polarity protection
- Type-C PD 3.0: 60W output (5V / 9V / 12V / 15V / 20V at 3A)
- Dual USB-A QC 3.0 (orange): 18W max each (5V/3A, 9V/2A, 12V/1.5A)
- Protocol support: BC1.2, Apple, Samsung, QC 2.0, QC 3.0
- Included accessories: 0.75mm² DC5521 cable + MC4 adapter, 2mm² XT60 cable, XT60-to-MC4 cable, 2× carabiners
- Dimensions: 105 × 62 × 17 mm
- Input voltage range: DC 6-28V
- DC output: 6A max, unregulated, with 20A reverse-polarity diode
- Type-C PD 3.0: 60W output (5V / 9V / 12V / 15V / 20V at 3A)
- Dual USB-A QC 3.0 (orange): 18W max each
- Protocol support: BC1.2, Apple, Samsung, QC 2.0, QC 3.0
The optional quick-charge box for the 200W and 400W panels attaches to the panel frame and taps the XT60 output. This allows direct USB device charging from the high-power panels without a separate power station — useful for field teams running laptops and communication equipment.
Protocol compatibility matters for resellers. End users of portable solar panels arrive with phones and tablets from every brand and generation. BC1.2 covers all legacy BC-compliant devices (most Android phones pre-2017). Apple 2.4A delivers full-speed charging to iPhones and iPads without the "not charging" warning that appears with underspecified chargers. Samsung AFC and Samsung 2A cover Galaxy line devices. QC 2.0 / 3.0 handles Qualcomm-based Android phones up to 18W. PD 3.0 (60W/100W panels only) handles modern laptops, iPad Pro, MacBook Air, and USB-C Android flagships. This breadth of protocol support eliminates the "my phone won't charge from your solar panel" support calls that plague cheaper panels with single-protocol chipsets.Foldable vs Rigid Glass Panels: Which Is Right for Your Application?
We produce both the BF-PV-F foldable series and the BF-PV-P rigid glass series. The two form factors serve fundamentally different markets — this comparison helps you recommend the right type to your customers or choose correctly for your project deployment.| Parameter | BF-PV-F Foldable | BF-PV-P Rigid Glass |
|---|---|---|
| Portability | Folds to 50-75% smaller, 1-12 kg | Fixed size, heavier per watt (tempered glass + aluminum frame) |
| Deployment | Unfold in 30 seconds, carabiner mount | Permanent rack/roof mount, hardware needed |
| Durability | ETFE/PET lamination, suited for intermittent use | Tempered glass + aluminum frame, 25-year outdoor rated |
| Waterproofing | Panel rain-resistant; junction box not submersible | IP65 sealed throughout |
| Output Interface | Integrated quick-charge box (USB / PD / XT60) | MC4 DC output only |
| Ideal For | Camping, RV, emergency response, mobile charging | Rooftop install, off-grid power plants, permanent outdoor facilities |
| Shipping | 5x more units per container (folded packaging) | Bulky, fragile glass packaging |
Which Model Fits Your Application?
We designed the BF-PV-F lineup to cover the full range of portable solar use cases — from a 1 kg day-hike charger to a 12 kg construction-site power plant. Use this matrix to match your end-user scenario to the right SKU.
| Application | Recommended Model | Voltage | Why This Model |
|---|---|---|---|
| Day hiking / ultralight camping | BF-PV-F30W | 18V | Lightest (1 kg), fits in day pack, direct USB charging |
| Weekend car camping | BF-PV-F60W | 18V | Charges BF-PPS-300W in one day, PD 60W for laptops |
| Extended off-grid camping / RV | BF-PV-F100W | 18V | Charges BF-PPS-600W in one day, 3-fold compact storage |
| RV / mobile office full-day power | BF-PV-F200W | 36V | Charges BF-PPS-1500W in approximately 7h, 4-fold for vehicle roof |
| Construction site / food truck / off-grid cabin | BF-PV-F400W | 36V | Charges BF-PPS-3000W in approximately 9h, highest output for demanding loads |
| Emergency preparedness kits (retail) | BF-PV-F60W or BF-PV-F100W | 18V | Pre-packaged with power station as ready-to-sell kit |
| Government disaster relief stockpile | BF-PV-F100W + BF-PV-F200W | Mix | Medium + large panel covers all field scenarios |
| Outdoor rental fleet operator | BF-PV-F60W | 18V | Balance of output, durability, and per-unit cost at scale |
Certifications and Quality Assurance
We apply the same quality standards to our portable solar panels as we do to our solar street lights and power stations — production lines that have been shipping to 30+ countries since 2013.
Certifications held:- CE (European Conformity) — all models
- Monocrystalline cells sourced from tier-1 Chinese cell manufacturers with published efficiency data and batch traceability
- Cell efficiency spot-check — incoming cells verified against supplier efficiency rating using flash test equipment
- Lamination integrity test — adhesion strength and delamination resistance under thermal cycling
- Junction box waterproof seal test — IP rating verification on all sealed enclosures
- Folding hinge fatigue test — 1,000+ fold/unfold cycles simulated before production approval, ensuring the hinge mechanism withstands daily field use over multiple years
- Output power verification — every production batch tested under standard test conditions (STC: 1000W/m2, 25 degrees C, AM1.5) to confirm rated wattage output
- Manufacturing since 2013
- Shipped to 30+ countries across 6 continents
- 85% repeat order rate from B2B customers
- 0 customs seizure records
For specific market requirements — FCC (North America), RoHS (EU environmental compliance), UKCA (UK) — we can arrange additional third-party testing and certification upon request. Testing typically takes 2-4 weeks and costs are quoted per model.
How to Order: From Inquiry to Delivery
Step 1: Select Your Model and Quantity
Tell us which models you need, in what quantities, and for which market. We will provide FOB pricing, MOQ guidance, and lead time estimates. Response time: within 24 hours.
Step 2: Sample Evaluation
Order 1-2 sample units per model to test in your environment. Sample shipping worldwide via DHL/FedEx. We recommend testing solar output under local sunlight conditions, junction box charging performance, and fold/unfold durability. Sample cost applies toward your first bulk order.
Step 3: Bulk Order and Production
Confirm specifications, quantity, packaging, and branding requirements. We issue a proforma invoice. Payment: T/T 40% deposit, 60% balance before shipment (or as agreed in the contract). Production lead time: 15-30 days for standard models, 25-45 days for OEM/custom orders. Lead time depends on order specifications and quantity.
Step 4: Quality Inspection and Shipping
Every production batch undergoes output power verification, junction box function test, and folding hinge inspection. We send QC photos and test reports before packing. Third-party inspection (SGS, Bureau Veritas) welcome at our factory. We handle export documentation and customs paperwork.
Step 5: Delivery
FOB, CIF, or DDP to your port or warehouse. Foldable panels pack efficiently — approximately 5x more units per container compared to rigid glass panels of equivalent wattage. We provide professional packing with foam inserts to protect junction boxes and folding hinges during transit.
OEM Customization
| Customizable Item | Options | MOQ |
|---|---|---|
| Panel Wattage | Any value 30-400W | 200 pcs |
| Output Connector | DC5521 / XT60 / MC4 / Anderson | 100 pcs |
| Cable Length | Standard or custom (1-5m) | 100 pcs |
| Junction Box Config | USB only / USB+PD / XT60+MC4 / Custom | 200 pcs |
| Logo / Branding | Screen print or heat transfer | 100 pcs |
| Packaging | Custom retail box or bulk | 200 pcs |
| Color | Black / Dark grey / Camo / Custom | 500 pcs |
Contact our engineering team for custom specifications. DFM (Design for Manufacturability) review included in the quotation process.
Frequently Asked Questions
Start Your Portable Solar Panel Project
Whether you are building a retail product line for outdoor enthusiasts, sourcing emergency preparedness kits for government contracts, or supplying portable power bundles for your distribution network — we manufacture the panels and handle export logistics.
Ready to start?- Get a quote: Tell us your target models, quantity, and market. We respond within 24 hours with FOB pricing and lead time.
- Download spec sheets: Request detailed datasheets with dimensional drawings, electrical specifications, and certification documents for any model.
